Specifications: 1) Name: Material Supply Mining Car 2) Company: Shandong China Coal Industrial & Mining Supplies Group Co., Ltd. 3) Certificate: MA, ISO, SGS certificates 4) Origin: Jining, Shando
Contact Us Product Center
Specifications:
1) Name: Material Supply Mining Car
2) Company: Shandong China Coal Industrial & Mining Supplies Group Co., Ltd.
3) Certificate: MA, ISO, SGS certificates
4) Origin: Jining, Shandong Province, China
Features :
1) High reliability;
2) Long service time;
3) Low operational costs;
4) Made by high quality steel;
5) High Stress area welds eliminated;
6) Mass and section thickness optimized;
7) Simplified state of the art mainframe and easy to operate;
8) Easy replacement of wear and spare parts.
MAIN PARAMETER OF|
mine material car model |
MLC2-6 |
MLC3-6 |
MLC5-6 |
MLC5(3)-9 |
MLC3-9 |
|
loadage(t) |
2 |
3 |
5 |
5 |
3 |
|
track gauge(mm) |
600 |
600 |
600 |
900 |
900 |
|
contour dimension(mm) |
2000*880*1150 |
1050*1200*1200 |
3450*1200*1200 |
3450*1230*1200 |
2100*1150*1300 |
|
wheel base(mm) |
550 |
750 |
1100 |
1100 |
900 |
|
wheel diameter |
300 |
300 |
350 |
350 |
350 |
|
heigth of towing attachment(mm) |
320 |
320 |
320 |
320 |
320 |
|
allowed traction(kn) |
60 |
60 |
60 |
60 |
60 |
|
overall weight(kg) |
520 |
520 |
920 |
940 |
790 |
